Kyoritsu 5406
Rp 4,000,000
- Custom microprocessor controlled for highest accuracy and reliability.
- 3 LEDs for checking correct wiring status.
- 0 and 180 degree phase angle switch permits quick tests and consistent readings.
- Digital read-out of tripping time.
- Constant current source circuitry ensures that a fluctuating mains voltage does not affect the accuracy of readings.
- Large custom digital display readout.
- Visual indication of reversed phase and neutral wiring at socket.
- Designed to IP54 Rating.
- Complies with IEC 61557
| Specification | |
|---|---|
| Rated Tripping Current | |10/20/30/200/300/500mA |
| Fault Condition Settings | |× 1/2, × 1, × 5, × DC, |AUTO RAMP |
| Trip Current Duration | |1000ms, 200ms (×5) |
| Lowest Resolution | |1ms |
| Trip Time Accuracy | |±0.6%rdg±4dgt |
| Operating Voltage | |230V+10%-15% |(195V - 253V) 50Hz |
| Safety Standard | |IEC 61557-1,-6 |IEC 61010-1 CAT III 300V |IEC 61010-2-031 Pollution Degree 2 |
| Withstand Voltage | |3700V AC for 1 minute |
| IP Rating | |IEC 60529-IP54 |
| Dimensions | |186(L) × 167(W) × 89(D)mm |
| Weight | |800g approx. |
| Accessories | |Molded plug test leads |Pouch for test leads |Shoulder Strap |Instruction Manual |
| Optional | |7121B (Simplified measurement probe) |
